Installatieautomaat Ex9BH 2P C25
100400
8592765004017
Installatieautomaten Ex9BH worden toegepast in residentiële en industriële installaties. Ze zijn te combineren met een breed assortiment accessoires, zoals hulp- en signaalcontacten, uitschakelspoelen, onder- en overspanningsrelais en aardlekopbouwmodules. Alle componenten zijn onderling compatibel. Het aantal accessoires is alleen beperkt door het maximum aantal per automaat en niet door het type. Per automaat kunnen maximaal drie hulp- of signaalcontacten en twee uitschakelmodules worden gemonteerd.
| Release characteristic | C |
| Number of poles (total) | 2 |
| Number of protected poles | 2 |
| Nominal rated current [A] | 25 |
| Nominal rated voltage [V] | 400 |
| Rated short-circuit breaking capacity Icn EN 60898 at 230 V [kA] | 10 |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V [kA] | 15 |
| Voltage type | AC |
| Current limiting class | 3 |
| Frequency [Hz] | 50-60 |
| Concurrently switching N-neutral | No |
| Over voltage category | 3 |
| Pollution degree | 2 |
| Width in number of modular spacings | 2 |
| Built-in depth [mm] | 74 |
| Additional equipment possible | Yes |
| Degree of protection (IP) | IP20 |
| Power loss [W] | 7 |
