Installatieautomaat Ex9B125 3P C80A
102791
8592765027924
Installatieautomaten Ex9B125 voor energieverdeling in industriële installaties bieden bescherming tegen kortsluiting en overbelasting tot een nominale stroom van 100 A. Ze hebben een hoge uitschakelcapaciteit en voldoen aan EN 60947-2. De automaten zijn te combineren met een breed assortiment accessoires (gelijk aan de Ex9B-serie), zoals hulp- en signaalcontacten, uitschakelspoelen en onder- en overspanningsrelais. Combinaties van accessoires zijn mogelijk.
| Release characteristic | C |
| Number of poles (total) | 3 |
| Number of protected poles | 3 |
| Nominal rated current [A] | 80 |
| Nominal rated voltage [V] | 400 |
| Rated short-circuit breaking capacity Icn EN 60898 at 230 V [kA] | 15 |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V [kA] | 20 |
| Voltage type | AC |
| Current limiting class | 3 |
| Frequency [Hz] | 50-60 |
| Concurrently switching N-neutral | No |
| Over voltage category | 3 |
| Pollution degree | 3 |
| Width in number of modular spacings | 4.5 |
| Built-in depth [mm] | 75 |
| Additional equipment possible | Yes |
| Degree of protection (IP) | IP20 |
| Power loss [W] | 20.1 |
